INFORMATION DETAILS
ID: 227402
|
Year: 2007
|
Make: Eton
|
Model: Viper 90R
|
Type: New
|
| MSRP:
N/A |
Engine Size - cc: N/A |
SELLER DESCRIPTION
| ENGINE |
 |
| Type |
Four cycle air cooled |
| Displacement |
88.4cc |
| Bore / Stroke |
47mm x 51mm |
| Compression Ratio / Pressure |
10.2:1 |
| Power |
7HP |
| TRANSMISSION |
|
| Type |
Automatic (C.V.T. V-Belt) |
| CHASSIS |
 |
| Overall Length |
1500mm / 59.0" |
| Overall Width |
850mm / 33.5" |
| Overall Height |
940mm / 37" |
| Wheel Base |
1030mm / 46.6" |
| Ground Clearance |
127mm / 5" |
| Dry Weight |
115kg / 253.3lbs |
| SUSPENSION |
 |
| Front |
Dual A-arm with Adjustable Shocks |
| Rear |
Swing Arm Adjustable Shock |
| BRAKES |
 |
| Front |
Dual Mechanical drum |
| Rear |
Hydraulic Disc |
| TIRES |
 |
| Front |
18/7-8 |
| Rear |
18/9-8 |
| Tire Pressure |
Front |
Min |
3.2psi / 0.23kg/cm2 |
| Max |
4.0psi / 0.28kg/cm2 |
| Rear |
Min |
3.2psi / 0.23kg/cm2 |
| Max |
4.0psi / 0.28kg/cm2 |
| FLUIDS |
 |
| Fuel |
Type |
Unleaded Gasoline 89 octane |
| Volume |
4.5liters / 1.2gal |
| Engine Oil |
Type |
SAE 20W-40 |
| SPARK PLUG |
 |
| NGK |
BPR7HS |
| Electrode Gap |
0.6-0.7mm / 0.023" |
| SAFETY FEATURES |
 |
| Remote Control Stop/Start |
Optional Kit (Stop Only) |
| Safety Tether Switch |
N/A |
| Enclosed Foot Rest Area |
Standard equipment |
| Encloesed Engine Compartment |
N/A |
| Maximum Rider Weight |
68.2kg / 190lb |
| Minimum Rider Age |
12 years |
Available Colors
|
Red, Black/Silver *Subject to availability |
